Tabular alumina is made of Al2O3, after ingredients, grinding and forming, smelting in high temperature furnace turned to α- Al2O3.
Production feature:
Tabular alumina has good heat resistance and good bulk temperature thermal shock capabilities. The crystal staggered plate shape, to increasing the mechanical strength of the particles; interior structure full of closed pores, high bulk density, low apparent porosity and water absorption, to reducing the amount of fluid re-use productions; With good physical properties like: high refractoriness, excellent thermal shock resistance, low shrinkage and good thermal load strength etc. Meanwhile, high-purity avoiding damage to machines.
Production process
1.imported Australian alumina powder 2. Fine grinding
- Ball forming machine 4. Testing of raw balls
5.High temperature calcine 6. Extreme cooling
7.Cooked ball detection 8. Granulator
9.Sub-assembly Line 10. Determination of chemical constituents
11.physical property testing 12. Storage of qualified products
Application:
Tabular alumina is an ideal refractory material, either can be used in various refractory alumina, or can be add in other unshaped refractories
1) refractory materials, furnace charge,aggregate, castable , rammed miscellaneous materials, plastic, pressing materials, projection materials, spray paint, vibration materials, refractory mud
2) wear-resisting coating, refractory coating, wear-resisting machinery,
3) smelting, casting, steel mills, power plants
4) ceramic deburring , surface treatment
5) firebrick, fireproof ceramics
Style | chemical index | physical index | ||||||
Al2O3% | SiO2% | Fe2O3% | Na2O % | Volume density (g/cm3) | Water absorption | Apparent porosity | ||
0-1mm 1-3mm 3-5mm 5-8mm | 99.3min | 0.1 max | 0.02max | 0.4 max | 3.5 | 1.5 | 5max | |
200#-0 320#-0 325# | 99.1 min | 0.15 max | 0.04 max | 0.4 max | 3.45 | 2.0 | 6max |
